Epic Selectorized
ES816_3Q
ES816

LATERAL RAISE

The Freemotion EPIC Lateral Raise builds strength in the shoulders with arms that move independently to create single or dual exercises. Less time adjusting the fit on this machine means more time targeting coveted shoulder muscles to improve strength in everyday life. A new, lower tower height promotes an open feel.
ES816_3Q_Talent_Male

Unilateral Arm Movement

Handles move independently to create single or dual-arm exercises that build strength with balance and symmetry.

ES816_Cushion

Molded Arm Pads

Contoured to fit the shape of the body, the machine’s arm pad have been carefully molded to create a comfortable fit.

ES816_Tower-High-03

Low Profile Tower Design

The low profile tower works well with an open design floor plan and adds to the ‘welcome’ environment.

Details & Specs

ES816_3Q
  • Features
    Low Profile Tower Design

    The low profile tower works well with an open design floor plan and adds to the 'welcome' environment.

    Unilateral Arm Movement

    Handles move independently to create single or dual-arm exercises that build strength with balance and symmetry.

    Molded Arm Pads

    Contoured to fit the shape of the body, the machine's arm pad have been carefully molded to create a comfortable fit.

    Built-in Storage

    The redesigned top cap of this machine features a built-in accessory tray to help users keep track of their phone, keys and more.

    Smaller Footprint

    The new EPIC Lateral Raise has a smaller, narrower footprint to free up your square footage.

    Swiveling Handles

    Handles swivel to accommodate users of various body types.

    Multiple Seat Adjustments

    Seat adjusts to multiple positions to accommodate users of all sizes.

    Heavy Duty Cable

    Heavy duty cable is designed to support the rigorous usage demands of this machine.

    Heavy Duty Floor Protectors

    Made with molded rubber, the Freemotion floor guards help better protect your floor.

    Easy Serviceability

    The tower design allows for simple cable service.

  • Specifications
    Product Specifications
    • Standard Frame Colors Platinum Sparkle, Black River
    • Optional Frame Colors On Request
    • Plastic Colors Black
    • Standard Upholstery Colors Black
    • Optional Upholstery Colors Graphite, Blue Ridge, Burgundy, American Beauty Red
    • Hand Grip Colors Black
    Equipment Features
    • Instructional Placards Yes
    • Adjustments Multiple Seat Adjustments
    • Weight Stack lbs (kg) 205 lbs (92.9 kg)
    • Upholstery Vinyl, 1.5 in (3.8 cm) thick foam
    • Rubber Feet Heavy Duty Floor Protectors
    • Resistance lbs (kg) 205 lbs (92.9 kg)
    • Weight Stack Configuration lbs (kg) 10 lbs header (4.5 kg)
      20-180 x 10 lbs (4.5 kg)
      190-200 x 20 lbs (9 kg)
    • Maximum User Weight lbs (kg) 350 lbs (159 kg)
    • Drop Down Weight 5 lbs (2.2 kg)
    Product Dimensions & Weight
    • Machine Weight lbs (kg) 440.9 lbs (200 kg)
    • L x W x H in (cm) 33.4 x 45.3 x 57.8 in
      (84.8 x 115 x 146.8 cm)
    Shipping Dimensions & Weight
    • Shipping Weight lbs (kg) Box 1: 545.8 lbs (248.5 kg)
      Box 2: 13 lbs (5.8 kg)
    • L x W x H in (cm) Box 1: 75 x 29 x 46 in
      (190.5 x 73.6 x 116.8 cm)
      Box 2: 20.2 x 15.3 x 5.9 in
      (51.3 x 38.8 x 14.9 cm)
    Regulatory Approvals
    • Approvals CE
    Warranty (US)
    • Frame 10 Years
    • Parts 3 Years
    • Other 120 Days
    • Cables/Labor 1 Year
    Warranty (International)
    • Frame 10 Years
    • Parts 3 Years
    • Other 120 Days
    • Cables/Labor 1 Year
  • Documents
    PDF Downloads
ES816_3Q
